Compound Machining Additional Manual Page 82

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 82/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Count types (time or frequency) can be registered for individual groups.
Format Meaning of common
G10L3
( or
G10L3P1) ;
P__ L__ Q__ ;
T__ H__ D__ ;
P__ L__ Q__ ;
T__ H__ D__ ;
P__ L__ Q__ ;
T__ H__ D__ ;
G11 ;
M02(M30) ;
Q__ : Life count type (1:Frequency, 2:Time)
• Register of tool life count
type
Note
1.The group number specified by P need not be consecutive. All groups
need not be specified.
1. Same plural T numbers can exist in specified data repeatedly.
2. When Q command is omitted, a kind of life counter depends on the
setting of parameter 6800#2(LTM).
3. Whether tool life is to be indicated by time (minutes) or by frequency,
it is set by a parameter No.6800#2(NTM).
Maximum value of tool life is as follows.
In case of minute:4300(minutes)
In case of frequency:9999(times)
4. The execution of G10 L3 command must be done in milling mode.
