Compound Machining Additional Manual Page 90

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 90/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
3.4 DNC Operation
In the compound machining function, it is possible to perform DNC
Operation as follows.
3.4.1 I/O Channel
This function can be used under the following channels.
0∼2: RS232-C
3: Remote Buffer
5: Data Server
3.4.2 Note of DNC Operation
• During DNC operation, it is possible to command the M code in order to
change between the turning mode and the milling mode.
• During DNC operation, AI contour control is not available.
3.4.3 Scheduling Function and Sub Program Call Function(M198)
• The restrictions of this function are similar to standard FS16i/18i-TA and
FS16i/18i-MA.
• In the scheduling function, the screen where the selection of the execution
file, the execution order, and the number of repetitions are specified is
displayed in both T-DSP and M-DSP. And, they can be set on each screen.
• It is not possible to command the M code in order to change between the
turning mode and the milling mode during executing this function. P/S
alarm 5253 occurs in commanding it.
3.4.4 Data Server Function
• The data server maintenance screen is displayed in both the turning mode
and the milling mode, and data can be separately set. However, the DNC
operation executed in the milling mode operates according to the setting of
T-DSP.
• The Ethernet parameter screen and the Ethernet error message screen are
displayed only in T-DSP. It is not displayed in M-DSP.
