Compound Machining Additional Manual Page 28

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 28/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Address 7 6 5 4 3 2 1 0
G000 ED7 ED6 ED5 ED4 ED3 ED2 ED1 ED0
G001 ED15 ED14 ED13 ED12 ED11 ED10 ED9 ED8
G002 ESTB EA6 EA5 EA4 EA3 EA2 EA1 EA0
G003
G004 MFIN3 MFIN2 FIN
G005 BFIN AFL BFIN TFIN SFIN EFIN MFIN
G006 SKIPP OVC *ABSM SRN
G007 RLSOT EXLM *FLWP RLSOT3 ST STLK RVS
G008 ERS RRW *SP *ESP *IT
G009 PN16 PN8 PN4 PN2 PN1
G010 *JV7 *JV6 *JV5 *JV4 *JV3 *JV2 *JV1 *JV0
G011 *JV15 *JV14 *JV13 *JV12 *JV11 *JV10 *JV9 *JV8
G012 *FV7 *FV6 *FV5 *FV4 *FV3 *FV2 *FV1 *FV0
G013 *AFV7 *AFV6 *AFV5 *AFV4 *AFV3 *AFV2 *AFV1 *AFV0
G014 ROV2 ROV1
G015
G016 F1D MSDFON
G017
G018 HS2D HS2C HS2B HS2A HS1D HS1C HS1B HS1A
G019 RT MP2 MP1 HS3D HS3C HS3B HS3A
G020
