Compound Machining Additional Manual Page 116

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 116/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Setting and display
Item Specifications
Turning
mode
Milling
mode
Status display Ο
Clock function Ο
Current position display Ο
Program display Program name 31 characters Ο
Parameter setting and display Ο
Self-diagnosis function Ο
Alarm display Ο
Alarm history display Ο
Operator message history display
S
Operation history display Ο
Help function Ο
FACTOLINK -
Remote diagnostic Reading mounted PCB data,
reading CNC data such as parameter
and alarm status, etc.
-
Run hour and parts count display
I
Actual cutting feedrate display Ο
Display of spindle speed and
T code at all screens
Ο
Directory display of floppy cassette
I
Directory display and punch
for each group
Ο
Graphic function -
Dynamic graphic display -
Background graphic without CAP -
Optional path name display Ο
Servo setting screen Ο
Spindle setting screen Only for serial interface
S
Servo waveform display Graphic display circuit is required. -
