Compound Machining Additional Manual Page 20

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 20/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
2.3 Switching CNC screens for turning and milling modes
Some data such as parameters, offsets or so are independent for each
command mode, turning and milling, because different values should be
specified.
2.3.1 Display Switch Signal
There are separate CNC screens for modes, which can be switched by a PMC
signal DTM(G193#0).
Switching can be done at any timing.
On the mode-dependent screens, the data peculiar to modes are specified.
The data common for modes are displayed and specified on same screens
regardless of modes.
The following table shows the data common or independent for modes.
Screen Common or independent
Position independent
Program common
Current/Next block independent
Floppy directory common
Program common
Offset independent
Setting independent
Work coordinate system independent
Macro variable independent
Software operator’s panel independent
Tool life management only for milling
Workpiece shift only for turning
Parameter independent
Diagnosis independent
PMC common
System configuration common
Pitch error compensation only for turning
Servo parameter only for turning
Spindle parameter only for turning
Message independent
Message history independent
Alarm independent data displayed
on common screen
Alarm history independent
