Compound Machining Additional Manual Page 48

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 48/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Address 7 6 5 4 3 2 1 0
F125
F126
F127
F128
F129
*EAXSL
EOV0
F130 EBSYA EOTNA EOTPA EGENA EDENA EIALA ECKZA EINPA
F131
EABUFA
EMFA
F132 EM28A EM24A EM22A EM21A EM18A EM14A EM12A EM11A
F133 EBSYB EOTNB EOTPB EGENB EDENB EIALB ECKZB EINPB
F134
EABUFB
EMFB
F135 EM28B EM24B EM22B EM21B EM18B EM14B EM12B EM11B
F136 EBSYC EOTNC EOTPC EGENC EDENC EIALC ECKZC EINPC
F137
EABUFC
EMFC
F138 EM28C EM24C EM22C EM21C EM18C EM14C EM12C EM11C
F139 EBSYD EOTND EOTPD EGEND EDEND EIALD ECKZD EINPD
F140
EABUFD
EMFD
F141 EM28D EM24D EM22D EM21D EM18D EM14D EM12D EM11D
F142 EM48A EM44A EM42A EM41A EM38A EM34A EM32A EM31A
F143
F144
F145 EM48B EM44B EM42B EM41B EM38B EM34B EM32B EM31B
