Compound Machining Additional Manual Page 123

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 123/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
8.2 Manual Parameter Setting
8.2.1 Optional Parameter
l Procedure
1. You set the parameter no.13002#0(TMD) or the parameter no.13002#3
(MDD) to 1
2. You confirm the display “T-DSP” in the lower right of the screen. After
that, you set the parameter no. 9900 to 9999 according to the data sheet.
3. You turn the power of CNC off and turn it on.
Note
• In the compound machining function, the parameter of the milling side
(M-DSP) is automatically set according to the parameter of the turning
side (T-DSP). Therefore, you must not set the parameter no. 9000 to
9999 of the milling side (M-DSP).
The optional parameters for the exclusive use of the milling side are
prepared on the turning side (T-
DSP).
