1. Fanuc
  2. Compound Machining

Compound Machining Additional Manual Page 33

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 33/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Address 7 6 5 4 3 2 1 0
G105
G106 MI8 MI7 MI6 MI5 MI4 MI3 MI2 MI1
G107
G108 MLK8 MLK7 MLK6 MLK5 MLK4 MLK3 MLK2 MLK1
G109
G110 +LM8 +LM7 +LM6 +LM5 +LM4 +LM3 +LM2 +LM1
G111
G112 -LM8 -LM7 -LM6 -LM5 -LM4 -LM3 -LM2 -LM1
G113
G114 *+L8 *+L7 *+L6 *+L5 *+L4 *+L3 *+L2 *+L1
G115
G116 *-L8 *-L7 *-L6 *-L5 *-L4 *-L3 *-L2 *-L1
G117
G118 *+ED8 *+ED7 *+ED6 *+ED5 *+ED4 *+ED3 *+ED2 *+ED1
G119
G120 *-ED8 *-ED7 *-ED6 *-ED5 *-ED4 *-ED3 *-ED2 *-ED1
G121
PK7
G122
PKESS2
PKESS1
PK6 PK5 PK4 PK3 PK2 PK1
G123
G124 DTCH8 DTCH7 DTCH6 DTCH5 DTCH4 DTCH3 DTCH2 DTCH1
