Compound Machining Additional Manual Page 119

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 119/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Others
Item Specifications
Turning
mode
Milling
mode
Status output signal NC ready, servo ready, automatic
operation, automatic operation start lamp,
feed hold, reset, NC alarm, distribution
end, rewinding, inch input, cutting,
inposition, thread cutting, tapping, etc.
Ο
Control unit incorporated type 7.2” monochrome LCD
l
display unit 9.5” monochrome LCD
l
8.4” color LCD
l
10.4” color LCD
l
Control unit dimensions (depth) Without option slots (depth 60mm) -
Option 2 slots (depth 110mm)
l
Option 4 slots (depth 170mm)
l
MDI unit Separated MDI for 7.2”/8.4”LCD
(small size)
l
Separated MDI for 7.2”/8.4”LCD
(standard size)
l
Separated MDI for 9.5”/10.4”
(standard size, horizontal type)
l
Separated MDI for 9.5”/10.4”
(standard size, vertical type)
l
Separated MDI for 10.4”
(personal computer key, vertical type)
-
Touch panel (only for 10.4”LCD)
l
