Compound Machining Additional Manual Page 111

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 111/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Item Specifications
Turning
mode
Milling
mode
Symbolic CAP T basic module -
Symbolic CAP T C/Y axis module -
Auxiliary/spindle speed function
Item Specifications
Turning
mode
Milling
mode
Auxiliary function M8-digit Ο
2nd auxiliary function B8-digit
I
Auxiliary function lock Ο
High-speed M/S/T/B interface Ο
Waiting function -
Multiple command of
auxiliary function
3
Ο
M code group check
I
Spindle speed function S5-digit, binary output Ο
Spindle serial output S5-digit, serial output
I
3rd/4th spindle serial output
I
Spindle analog output S5-digit, analog output -
Constant surface speed control
I
Without position coder constant
surface speed control
I
-
Spindle override 0~254%
S
Actual spindle speed output
I
-
Spindle speed fluctuation detection
I
