3.PERIPHERAL EQUIPMENT CONTROL HANDLING B-65395EN/01

- 72 -

3.1 COMMAND FORMAT FOR PERIPHERAL EQUIPMENT

CONTROL

The servo amplifier module receives a command, issued in the specified

format, from the host, then executes a sequence of operations for

performing peripheral equipment control. When a command for reading

the current position is specified, the servo amplifier module returns the

result of command execution to the host. The command and result are

exchanged, in an interface area, in the formats shown below.

● General format of instruction commands (host → servo amplifier

module)

7 6 5 4 3 2 1 0

Yy+2 Function code Command data 1

Yy+3

Yy+4 Command data 2

Yy+5

Yy+6

●

General format of response commands (servo amplifier module →

host)

7 6 5 4 3 2 1 0

Xx+3

Xx+4 Response data

Xx+5

Xx+6

● Data types

7 6 5 4 3 2 1 0 BIT

Byte type:

(BYTE)

7 6 5 4 3 2 1 0 BIT

Word type: Lower byte

(WORD) Higher byte

Data = (higher byte)*256 + (lower byte)

7 6 5 4 3 2 1 0 BIT

Lowest byte

Second lowest byte

Second highest byte

Double

precision

type

(DWORD):

Highest byte

Data = (highest byte)*16777216

+ (second highest byte)* 65536

+ (second lowest byte)*256

+ (lowest byte)
