SERVO AMPLIFIER Beta i series Maintenance manual Page 267

Maintenance manual
B-65395EN/01 APPENDIX B.PARAMETER LIST
- 235 -
B PARAMETER LIST
Table B (a) Parameter list (in order of classification)
Classification Parameter number Reference
item
Controlled-axis parameter 000 B.1
Coordinate system and
stroke limit parameters
001, 068, 140 to 145, 147,
154 to 165, 170
B.2
Feedrate parameters
021, 040, 041, 043 to 050, 054,
061, 066, 067
B.3
Acceleration/deceleration
parameters
002, 055 to 060 B.4
Input/output signal
parameters
003 to 005, 007, 020, 022 to
025, 029, 062, 063, 148 to 152,166 to
169
B.5
Servo parameters
010 to 014, 016 to 019, 030 to 032,
070 to 075, 078 to 096, 099 to 112,
115, 116, 118, 119, 125, 130, 135 to
138, 179 to 182
B.6
