3.PERIPHERAL EQUIPMENT CONTROL HANDLING B-65395EN/01

- 126 -

NOTE

1 This signal is effective if bit 5 (MP) of parameter No. 5

of the servo amplifier module is 1.

2 This signal is effective in manual handle mode only.

3 This signal shares the same bits with the rapid traverse

override signal. In manual handle mode, these bits are

for the incremental feed signal; in modes other than

manual handle mode, they are for the rapid traverse

override signal. Before switching from manual handle

mode to another mode, this signal must be returned to

such a setting that the bits are for the rapid traverse

override signal.

3.10.3.2 Signal on the CNC (host)

7 6 5 4 3 2 1 0

G199 IOLBH3 IOLBH2

Manual handle feed generator select signals IOLBH2 and IOLBH3

[Classification] Input signal <G199#0,#1>

[Function] These signals are used to select the manual pulse generator used to feed

the servo amplifier module.

[Operation] These signals are used to select the manual pulse generator used to feed

the servo amplifier module.

IOLBH3 IOLBH2

Manual pulse generator used to feed the servo

amplifier module

0 0 1st

0 1 2nd

1 0 3rd

1 1 Not for use

NOTE

1 Do not switch manual pulse generators in manual

handle mode.

2 Up to two generators can be selected if the manual

pulse generator interface is the connector (JA47) on

the base PCB on Power Mate i-D/H.
