B-65395EN/01 APPENDIX B.PARAMETER LIST

- 263 -

167 Time between servo-on and unclamping

[Size] 4-byte

[Unit of data] 8msec

[Valid data range] 0 to 99999999

[Standard value] 0

[Description] Specifies a time interval from the time the servo system is switched on

until the machine is unclamped if clamping/unclamping is used.

168 Time between clamping and servo-off

[Size] 4-byte

[Unit of data] 8msec

[Valid data range] 0 to 99999999

[Standard value] 0

[Description] Specifies a time interval from the time the machine is clamped until the

servo system is switched off if clamping/unclamping is used.

169

Time allowed before the next sequence is executed without

clamping/unclamping

[Size] 4-byte

[Unit of data] 8msec

[Valid data range] 0 to 99999999

[Standard value] 0

[Description] Specifies a time interval from the time the clamp/unclamp command

(UCPC2) is issued until the next sequence is started, if the

clamp/unclamp state signal (UCPS2) is not to be checked. Whether to

check the clamp/unclamp state signal (UCPS2) is specified using bit 2

of parameter No. 003 (IGCP).
