B-65395EN/01 HANDLING 2.SIGNAL DESCRIPTIONS

- 61 -

(6) Response data check signals DSP1 and DSP2

[Classification] Input signal <Xx+2#4 to #5>

[Function] The servo amplifier module indicates the contents of the response data.

[Input condition] The servo amplifier module specifies the response data using a

combination of signals, as listed below.

DSP2 DSP1 Response data

0 0 Not output

1 1

Coordinates, motor current value, skip

measurement data, or torque command

1 0 Current position number (ATC, point number)

0 1 Actual feedrate or actual speed

NOTE

1 The setting of parameter No. 20 determines which

of coordinates, motor current value, skip

measurement data, and torque command the

response data is.

2 The setting of parameter No. 20 determines which

of actual feedrate and actual speed the response

data is.

(7) Response data write completion signal ABSWT

[Classification] Input signal <Xx+1#0>

[Function] After writing response data (Xx+3 to Xx+6), the servo amplifier

module inverts this signal for notification to the host.

[Operation] The servo amplifier module exclusive-ORs ABSWT with ABSRD.

When the result of exclusive-OR is 0, response data (Xx+3 to Xx+6) is

written, and this signal is inverted.

(8) Response data read completion signal ABSRD

[Classification] Output signal <Yy+1#4>

[Function] After reading response data (Xx+3 to Xx+6), the host inverts this signal

for notification to the servo amplifier module.

[Operation] The host exclusive-ORs ABSWT with ABSRD. When the result of

exclusive-OR is 1, response data (Xx+3 to Xx+6) is read, and this

signal is inverted.

(9) Alarm output command signal DSAL

[Classification] Output signal <Yy+0#3>

[Function] The host specifies that alarm information be output as response data.

When DSAL is 1, the following information is output as response data.

Xx+3 Number of alarms (byte type)

Xx+4,Xx+5 Alarm number (word type)

[Operation] When the signal is 0, a turret, magazine, point number, coordinates, or

motor current value are output as response data. When the signal is 1,

the number of alarms and the first alarm number are output as response

data.
