3.PERIPHERAL EQUIPMENT CONTROL HANDLING B-65395EN/01
- 74 -
3.3 FUNCTION CODES
3.3.1 Function Codes
Function code
Command data 1
4 bits
Command data 2
4 bytes
Mode
Start
signal
Remarks
0 : Jog operation JOG +X/-X (Note 1)
1: Automatic operation (shortcut
rotation)
2: Automatic operation (positive
direction)
3: Automatic operation (negative
direction)
Turret/magazine
number
AUTO ST
2 : ATC
operation/turr
et control
4 : 1-pitch rotation
5 : Continuous indexing (Note 2)
JOG +X/-X
Set an amount of travel per
ATC rotation and the
number of
turrets/magazines in the
parameters.
(Note 3, Note 4, Note 8)
3 : Point
positioning
Feedrate code 1 to 7
15: Rapid traverse
Point number
1 to 12
AUTO ST
(Note 5, Note 6, Note 7,
Note 8)
Reference position number
1: First reference position
2: Second reference position
3: Third reference position
ST
15: Reference position setting (Note
9, Note 10)
+X/-X
4 : Reference
position
return
15: Reference position external
setting (Note 11)
JOG
ST
5 : Positioning
(absolute
specification)
Feedrate code 1 to 7
15: Rapid traverse
Workpiece
coordinates
AUTO ST (Note 6)
6 : Positioning
(incremental
specification)
Feedrate code 1 to 7
15: Rapid traverse
Travel distance AUTO ST (Note 6)
7 : Speed control
0: Start-up or change-gear command
1: Stop command
Speed command
value
AUTO ST (Note 12)
BIT3: 0(absolute specification)
BIT0-2: Feedrate code 1 to 7
Workpiece
coordinates
8 : Positioning
(for skip
function)
BIT3: 0(incremental specification)
BIT0-2: Feedrate code 1 to 7
Travel distance
AUTO ST (Note 6, Note 13, Note 14)
10: Coordinate
system
setting
1: Coordinate system setting
2: Magazine number setting
3: Point number setting
Coordinates
Magazine number
Point number
AUTO ST
The coordinates
corresponding to a number
represent the current
position.
12 : Parameter
rewriting
Parameter type
1: Byte
2: Word
3: Two-word (1st)
4: Two-word (2nd)
Parameter number
and parameter
value
ST
14 : Point data
external
setting
Point number 1 to 12 Point data JOG ST
Data is entered into the
parameter corresponding to
a point number.
15 : Data setting
by teaching
Point number
1 to 12
JOG ST
A coordinate is entered into
the parameter
corresponding to a point
number.
