SERVO AMPLIFIER Beta i series Maintenance manual Page 215

Maintenance manual

Page of 366

/ 366

B-65395EN/01HANDLING 6.UNEXPECTED DISTURBANCE TORQUE DETECTION FUNCTION

- 183 -

096 Unexpected disturbance torque detection: alarm threshold value

[Size] 2-byte

[Unit of data] Torque command unit

[Valid data range] 0 to 7282 (7282 is the maximum current value of the amplifier)

Set a limit (threshold) value at which an unexpected disturbance torque

detection alarm is issued. If the setting is 0, processing for unexpected

disturbance torque detection is disabled, and alarm detection and

calculation of an estimated load torque are not performed.

First set bit 1 (TDOU) of parameter No. 014 to 1 (bit 0 of parameter

No.014 must be 0), and observe load torque. Then, set parameter No.

096 to a value greater than the maximum torque value.

6.6 ALARM

Number LED

indication

Description Action

409

An abnormal load is detected.

Look for the mechanical cause of the

abnormal load. If there is no

mechanical cause, increase the

check amount of the parameter (No.

096).

6.7 DIAGNOSIS

(DGN number) 7 6 5 4 3 2 1 0

034

ABTDTC

ABTDTC Unexpected disturbance torque detection function is:

0 : Disabled.

1 : Enabled.
