3.PERIPHERAL EQUIPMENT CONTROL HANDLING B-65395EN/01

- 76 -

3.4 DETAILS OF FUNCTION CODES

3.4.1 ATC/Turret Control

Command data 1 (feed type code)

Move command execution, automatic

operation start state

(2) Operation completion signal OPC 1: Unclamp command signal (UCPC2)

Servo amplifier module

operation state

Jog or Auto mode

Start enabled state

Host NC

CNC PMC

(1) O 0001

T ××

Function code = 2

Unclamp completion

(UCPS2=1) Operation completion signal OPC2

(3) Operation completion signal OPC 3: Clamp command signal (UCPC2)

ST signal, or +X/-X signal

(4) Clamp completion

Command data 2 (turret/magazine number)

(5) (UCPS2=0) Response data (turret/magazine number or coordinates)

Operation completion signal OPC4

Processi

ng by

PMC

Processing

by PMC

Processing

by PMC

FIN

When execution

has terminated

abnormally

Start enabled state

larm state occurrence

L signal and the number of

alarms/alarm numbers

(6) Alarm indication

(1) When the host NC program executes a T code command, the PMC

on the host NC sets the function code, command data 1, and

command data 2, then sends the ST signal or +X/-X signal to the

servo amplifier module. Upon receipt of the data, the servo

amplifier module returns the operation completion signal OPC 1

to the host NC, and also outputs the unclamp command signal.

(2) When unclamp completion notification is sent from the host NC,

the servo amplifier unit returns the operation completion signal

OPC 2 to the host NC, then starts movement to the position

corresponding to a specified turret/magazine number.
