B-65395EN/01 HANDLING 4.DIRECT COMMANDS

- 147 -

(10) Reading data continuously

This function reads from the host the absolute position, machine

position, servo positional deviation, etc. of the servo amplifier

module continuously.

● Instruction command format

#7 #6 #5 #4 #3 #2 #1 #0

Yy+4 Control flag 1

Yy+5 0 1 0 0 0 0 0 1 (0x41)

Yy+6 Number of data items to be read (*1)

Read data specification 1

Read data specification ｎ

(*1) Up to four data items can be specified for reading. When

continuous read operation is canceled, the host sets 0 as the

number of data items.

● Response command format

#7 #6 #5 #4 #3 #2 #1 #0

Xx+4 Control flag 2

Xx+5 0 1 0 0 0 0 0 1 (0x41)

Xx+6 Reserved Execution result

Continuously read data 1

Continuously read data n

NOTE

1 The data length varies according to the specified

data.

2 If a stop command (number of items: 0) is issued,

"0x80" is output as a completion code to Xx+6.

When this response command is read and

EOREND is inverted, continuous data reading ends.

3 If ECONT is "1", this indicates that there is

remaining response command(s). After the current

response command is read, inverting EOREND

causes the remaining command to be output from

Xx+5. Repeat this operation until ECONT becomes

"0".
