B-65395EN/01 START-UP PROCEDURE 3.START-UP PROCEDURE

- 13 -

<7> Set the number of pulses per revolution

The number of pulses per revolution is calculated with

reduction ratios or leads of the ball screws and detection unit.

(Number of pulses per motor revolution)

= (amount of travel per motor revolution) / (detection unit)

Numerator for the number of pulses

per rotation

(Parameter No. 105) (≤32767)

Denominator for the number of

pulses per rotation

(Parameter No. 106) (≤32767)

(Parameter No. 179) (>32767)

(Parameter No. 106) (≤32767)

Example of setting)

Example: 10um detection in semi-closed loop

Ball screw lead Number of pulses per rotation

Numerator/denominator

10 (mm/rev)

20 (mm/rev)

30 (mm/rev)

10mm/10µm=1000/1

20mm/10µm=2000/1

30mm/10µm=3000/1

Example of setting)

1/100 degree detection with a deceleration ratio of 10:1 for a

rotation axis

Every time the motor makes one rotation, the table rotates through 360/10

degrees. The number of pulses per motor rotation is 360/10 ÷ (1/100) = 3600

pulses, so set the ollowing:Numerator = 3600, Denominator = 1

<8> Set the direction of motor travel in parameter No. 31.

111 Clockwise as viewed from the pulse coder

-111 Counterclockwise as viewed from the pulse coder

<9> Set the reference counter capacity. (Parameter No. 180)

Set the reference counter capacity when performing a

reference position return operation based on the grid method.

Set the number of position pulses per motor rotation, or set

that number divided by an integer.

Example of setting)

αi pulse coders, semi-closed loop (1µmm detection)

Ball screw lead

Number of

pulses per motor

revolution

Reference

counter

Grid width

10mm/revolution

10000/1

20000/1

30000/1

10000

20000

30000

10mm

20mm

30mm
