SERVO AMPLIFIER Beta i series Maintenance manual Page 316

Maintenance manual
B.PARAMETER LIST APPENDIX B-65395EN/01
- 284 -
No
138 Expanded command multiplier (EXCMR)
[Size] 2-byte
[Valid data range] 2 to 400
[Standard value] 0
Specify a ratio of the user-specified unit to the detection unit.
K ＝ (K ≥ 1)
EXCMR = 2 × K
Enter an EXCMR value according to the above formula. Note that K
can be a value of 1 to 200.
NOTE
1 Always set an even number for EXCMR.
2 When K < 1, set bit 6 (ECMR) of parameter No. 010
to 0, and set the command multiplier in parameter
No. 032.
3 See the notes on parameter No. 032 because they
are also related to this parameter.
4 When bit 6 (ECMR) of parameter No. 010 is 1, read
parameter No. 032 in this manual as parameter No.
138.
No
179 Numerator for the number of pulses per motor revolution
[Size] 4-byte
[Valid data range] 0 to 8388607
[Standard value] 0
For the numerator for the number of pulses per motor revolution, the
setting of parameter No. 179 is valid when parameter No. 105 is 0.
When parameter No. 105 is a nonzero value, the value of parameter No.
105 is valid.
For the denominator for the number of pulses per motor revolution, the
setting of parameter No. 106 is always valid.
NOTE
1 If parameter No. 105 is 0 and parameter No. 179 is
greater than 8388607, an illegal parameter setting
alarm (417) is issued.
2 If parameter No. 105 is 0 and parameter No. 179 is
smaller than parameter No. 106, an illegal
parameter setting alarm (417) is issued.
3 See the notes on parameter No.105 because they
are also related to this parameter.
4 When this parameter is valid (parameter No. 105 is
0), read parameter No. 105 in this manual as
parameter No. 179.
User-specified unit
Detection unit
