3.PERIPHERAL EQUIPMENT CONTROL HANDLING B-65395EN/01
- 108 -
3.7 UPGRADING OF THE CLAMP/UNCLAMP CONTROL
FUNCTION
3.7.1 Start of the Timer Counting Until Servo-off in Clamp
Processing
3.7.1.1 Explanation of function
In clamp processing, the timer (parameter No. 0168) counting until
servo-off can be started when the clamp/unclamp state output signal is
turned off.
3.7.1.2 Parameter
No #7 #6 #5 #4 #3 #2 #1 #0
005
CLPSVF
[Size] 1 byte (bit type)
[Standard value] 0
CLPSVF As a period of time from the start of clamp processing to servo-off
(parameter No. 0168):
0 : Time after the unclamp command signal (UCPC2) is turned off is
set.
1 : Time after the clamp/unclamp state output signal (UCPS2) is set.
3.7.2 Disabling of Clamp Processing When Jog Operation is
Stopped
3.7.2.1 Explanation of function
When jog operation is stopped, clamp processing is not performed, but
the unclamp state can be held.
3.7.2.2 Parameter
No #7 #6 #5 #4 #3 #2 #1 #0
005
JNCL
[Size] 1 byte (bit type)
[Standard value] 0
JNCL When jog operation is stopped, clamp processing is:
0 : Performed.
1 : Not performed. (The unclamp state is held.)
