SERVO AMPLIFIER Beta i series Maintenance manual Page 303

Maintenance manual
B-65395EN/01 APPENDIX B.PARAMETER LIST
- 271 -
NOTE
1 If K is equal to or greater than 2, servo alarm No.
405 may be issued during reference position return.
In this case, set N405 (bit 4 of parameter No. 0001)
to "1" to prevent the alarm from being issued.
2 When K > 48, bit 6 (ECMR) of parameter No. 010 to
1, and set the expanded command multiplier
(EXCMR) in parameter No. 138. Up to 200 can be
specified for K.
No
070 Current loop gain (PK1)
[Size] 2-byte
[Valid data range] 1 to 32767
Do not change the standard setting.
No
071 Current loop gain (PK2)
[Size] 2-byte
[Valid data range] -1 to -32768
Do not change the standard setting.
No
072 Current loop gain (PK3)
[Size] 2-byte
[Valid data range] -1 to -32768
Do not change the standard setting.
No
073 Velocity loop gain (PK1V)
[Size] 2-byte
[Valid data range] 1 to 32767
No
074 Velocity loop gain (PK2V)
[Size] 2-byte
[Valid data range] -1 to -32768
No
075 Velocity loop gain (PK4V)
[Valid data range] -1 to -32768
Do not change the standard setting.
