SERVO AMPLIFIER Beta i series Maintenance manual Page 183

Maintenance manual
B-65395EN/01 HANDLING 4.DIRECT COMMANDS
- 151 -
(g) Reading the motor current value 0x0D
● Data specification code for continuous read
#7 #6 #5 #4 #3 #2 #1 #0
0 0 0 0 0 1 1 0 1 (0x0D)
1 0 0 0 0 0 0 0 1
● Continuous read data format
#7 #6 #5 #4 #3 #2 #1 #0
0 0 0 0 0 1 1 0 1 (0x0D)
1 Reserved Execution result
2
3
4
5
Motor current value data (DWORD type)
The motor current value means the maximum current
value of the amplifier when it is 6554.
(h) Reading the torque command 0x0E
● Data specification code for continuous read
#7 #6 #5 #4 #3 #2 #1 #0
0 0 0 0 0 1 1 1 0 (0x0E)
1 0 0 0 0 0 0 0 1
● Continuous read data format
#7 #6 #5 #4 #3 #2 #1 #0
0 0 0 0 0 1 1 1 0 (0x0E)
1 Reserved Execution result
2
3
4
5
Torque command data (DWORD type)
The maximum value of the torque command is 6554.
The least significant bit of the torque command means
the torque limit arrival signal.
The least significant bit of the torque command =
0: The torque limit has not been reached.
1: The torque limit has been reached.
