B-65395EN/01 HANDLING 2.SIGNAL DESCRIPTIONS

- 49 -

(3) Acceleration/deceleration pulse signal SUPX

[Classification] Input signal <Xx+0#2> (common to both the peripheral equipment

control and direct command interfaces)

[Function] This signal indicates that the servo amplifier module has accumulated

pulses in the acceleration/deceleration control section.

[Input condition] The signal becomes 1 when:

1. Axis movement distribution pulses are accumulated in the

acceleration/deceleration control section.

The signal becomes 0 when:

1. No axis movement distribution pulses are accumulated in the

acceleration/deceleration control section.

(4) In-position signal INPX

[Classification] Input signal <Xx+0#3> (common to both the peripheral equipment

control and direct command interfaces)

[Function] This signal indicates that the controlled axis is in position (has reached

the specified value).

[Input condition] The signal becomes 1 when:

1. There is no acceleration/deceleration delay (accumulated pulses)

for the controlled axis, and the servo positional deviation is within

a parameter-specified range.

The signal becomes 0 when:

1. There is an acceleration/deceleration delay (accumulated pulses)

for the controlled axis, or

2. The servo positional deviation falls outside a parameter-specified

range.

(5) Servo positional deviation monitor signal SVERX

[Classification] Input signal <Xx+7#6> (peripheral equipment control interface)

<Xx+3#6> (direct command interface)

[Function] This signal indicates that, in the servo amplifier module, the amount of

servo positional deviation has exceeded a parameter-specified value.

[Input condition] The signal becomes 1 when:

1. The servo positional deviation amount is larger than a

parameter-specified value.

The signal becomes 0 when:

1. A parameter-specified value for the servo positional deviation

amount is 0, or

2. The servo positional deviation amount is within a

parameter-specified range.

(6) Axis movement in-progress signal MVX

[Classification] Input signal <Xx+7#2> (peripheral equipment control interface)

<Xx+3#2> (direct command interface)

[Function] The signal indicates that movement along the controlled axis is being

performed.

[Input condition] The signal becomes 1 when:

1. Controlled axis movement begins.

2. Bit 7 (SVFP) of parameter No. 010 is set to 1 to perform follow-up

in clamp processing or servo-off state, and the servo position

deviation amount (DGN No. 032) is not zero.
