B.PARAMETER LIST APPENDIX B-65395EN/01

- 272 -

078 Current compensation 1 (PVPA)

[Size] 2-byte

[Valid data range] -1 to -32768

Do not change the standard setting.

079 Current compensation 2 (PALPH)

[Size] 2-byte

[Valid data range] -1 to -32768

Do not change the standard setting.

080 Current limit value (TQLIM)

[Size] 2-byte

[Valid data range] 0 to 7282

Do not change the standard setting.

081 Overload protection coefficient (POVC1)

[Size] 2-byte

[Valid data range] 0 to 32767

This is a coefficient for an alarm used to protect the motor and servo

amplifier from overload.

Do not change the standard setting.

082 Overload protection coefficient (POVC2)

[Size] 2-byte

[Valid data range] 0 to 32767

This is a coefficient for an alarm used to protect the motor and servo

amplifier from overload.

Do not change the standard setting.

083 Overload protection coefficient (POVCLM)

[Size] 2-byte

[Valid data range] 0 to 32767

This is a coefficient for an alarm used to protect the motor and servo

amplifier from overload.

Do not change the standard setting.

084 Current compensation 3 (AALPH)

[Size] 2-byte

[Valid data range] 0 to 32767

Do not change the standard setting.
