2.SIGNAL DESCRIPTIONS HANDLING B-65395EN/01

- 64 -

(7) Response data readable signal EOSTB

[Classification] Input signal <Xx+4#6>

[Function] The servo amplifier module indicates that data requested using a

function code command has been output as response data and is now

readable.

[Input condition] The state of the signal is inverted when:

1. The response data becomes readable.

(8) Response data read completion signal EOREND

[Classification] Output signal <Yy+4#6>

[Function] The host notifies the servo amplifier module that it has read response

data.

[Operation] When the state of the signal is inverted, the servo amplifier module

behaves as follows:

1. The result of function code command execution is output as

response data.

2. If a function code command is a data output command, the

command is executed, and the result is output as response data.

NOTE

If the result of exclusive-ORing EOSTB with

EOREND is 1, it becomes impossible to output

further command data. Before inverting the state of

EOREND, apply appropriate countermeasures.

(9) Command continuation notification signal ECNT

[Classification] Output signal <Yy+4#0>

[Function] When the host has too much command data to be sent at one time, it sets

the ECNT signal to 1 to inform the slave that remaining data exists.

[Operation] When the ECNT signal becomes 1, the servo amplifier module behaves

as follows:

1. After receiving command data from the buffer, the servo amplifier

module inverts the state of the EBSY signal so that it matches the

state of the EBUF, thereby prompting the transfer of the next data.

The signal is reset to 0 at the last data of a series of commands.

(10) PMM data signal USR1

[Classification] Input signal <Xx+4#3>

[Function] Direct commands transfer data using the same area as the power mate

CNC manager function. If USR1 is 0, it is necessary to perform special

processing to read the data, because it is a response from the ladder

program of the host. If USR1 is 1, the response command (Xx+4 and

after) is for the power mate CNC manager and, therefore, the ladder

program on the host ignores it.

[Input condition] The signal becomes 1 when:

1. The response data is power mate CNC data.

The signal becomes 0 when:

1. The response data is data from a ladder program.
