4.DIRECT COMMANDS HANDLING B-65395EN/01

- 164 -

136 Velocity deviation check limit during velocity control

[Size] 2-byte

[Unit of data] min

-1

[Valid data range] 0 to 4000

[Standard value] 0 (velocity deviation check not performed)

Set the limit on the velocity deviation check to be performed in velocity

control mode.

In velocity control mode, alarm No. 447 is issued if the deviation of the

actual velocity from the specified velocity exceeds the value set for this

parameter.

● Signal

7 6 5 4 3 2 1 0 BIT

Xx+2 TRQM

Speed control mode signal TRQM

[Classification] Input signal <Xx+2#2>

[Function] The servo amplifier module notifies that the system is in speed control

mode.

[Input condition] The signal becomes 1 when:

1. Speed control is started and the system is in speed control mode.

The signal becomes 0 when:

1. A speed control stop command is executed.

2. A servo alarm, overtravel alarm, reset, emergency stop, or servo

off

● Alarm

No.

LED

indication

Description Action

250

Command data 1 (peripheral

equipment control) or instruction

command (direct command) is

invalid.

Check the specified value of

command data 1 of peripheral

equipment control/function code

command.

Check the specified value of the direct

command (instruction command).

254

The function code or mode is invalid.

Check the specified value of the

function code of the function code

command. Check the mode.

255

An attempt to start fails because the

mode is wrong or a block is being

executed.

Check the mode. Check if a block is

being executed.

447

Too much speed deviation (speed

control)

Check the actual speed. Check the

contents of parameter No. 136.
