2.SIGNAL DESCRIPTIONS HANDLING B-65395EN/01

- 58 -

2.3.13 Peripheral Equipment Control Function Code and Related

Information

(1) Operation completion signals OPC1, OPC2, OPC3, and OPC4

[Classification] Input signal <Xx+0#4 to #7>

[Function] The servo amplifier module indicates information about the completion

of each function code. The host executes its sequence according to this

signal.

[Input condition] See the timing chart of each function code for the corresponding input

timing.

OPC1 indicates, to the host, that the servo amplifier module has

received a command.

The servo amplifier module issues an unclamp command signal

(UCPC2 = 1) to request the host to unclamp the machine.

OPC2 indicates, to the host, that the servo amplifier module has

received an unclamp completed command signal (UCPS2 = 1). The

servo amplifier module starts axis operation.

OPC3 indicates, to the host, that an axis operation is completed and the

in-position state is assumed, simultaneously as the clamp command

(UCPC2 = 0).

OPC4 indicates, to the host, that the servo amplifier module has

received the clamp completion signal (UCPS2 = 0) and finished

executing all commands.

The timing at which the signal is input is set in parameter No. 166.

CAUTION

If the unclamp command signal (UCPC2) and the

clamp/unclamp state output signal (UCPS2) are not

used (bit 1 (NCLP) of parameter No. 003 = 1), OPC4

is output to the host even if the instruction command

is interrupted due to an external reset, emergency

stop, alarm, etc.

NOTE

When the unclamp command signal (UCPC2) and

clamp/unclamp state output signal (UCPS2) are not

used (when bit 1 (NCLP) of parameter No. 003 = 1),

OPC2 and OPC3 are not output to the host. In this

case, OPC4 is output to the host when an axis

operation is completed and the in-position state is

assumed.

(2) Function code

[Classification] Output signal <Yy+2#4 to #7>

[Function] The host sets the peripheral equipment control function code.

[Output condition] See the timing chart of each function code for the corresponding output

timing. See Sections 3.3 and 3.4 for details.
