B.PARAMETER LIST APPENDIX B-65395EN/01
- 268 -
No #7 #6 #5 #4 #3 #2 #1 #0
016 FFAL FFVL LVMD PIIP
[Size] 1 byte (bit type)
[Standard value] 0
PIIP 0 : Specifies that the velocity loop be subject to PI control.
1 : Specifies that the velocity loop be subject to IP control.
LVMD 0 : Disables the low-velocity integration function.
1 : Enables the low-velocity integration function.
FFVL, FFAL Specify whether to enable the feed-forward function.
The feed-forward function is enabled only when FFVL and FFAL are 1.
FFVL FFAL Description
1 1 The feed-forward function is enabled.
0 * The feed-forward function is disabled regardless of
whether FFAL is 1.
1 0 The feed-forward function is disabled.
No #7 #6 #5 #4 #3 #2 #1 #0
017 SPCO HEDG HENB
[Size] 1 byte (bit type)
[Standard value] 0
HENB Specifies whether to use the skip function.
0 : The skip function is not used.
1 : The skip function is used.
HEDG When a skip signal is used with the skip function:
0 : The skip signal is handled as an input signal on the rising edge (0
→ 1).
1 : The skip signal is handled as an input signal on the falling edge(1
→ 0).
SPCO During execution of the skip function, if a skip signal (HDI) is not input
and the end point is reached:
0 : The data on the last skip measurement is retained.
1 : Specified coordinates of the end point are recorded as skip
measurement data.
No
030 Set 0. Set the motor type number in parameter No. 125.
Set parameter No. 030 to 0, and set the motor type number in parameter
No. 125.
