B.PARAMETER LIST APPENDIX B-65395EN/01

- 262 -

150

Coordinates (minimum) for point 1 in the operation range of the area

signals

151 Coordinates for point 2 in the operation range of the area signals

152 Coordinates for point 3 in the operation range of the area signals

[Size] 4-byte

[Unit of data] User-specified unit

[Valid data range] 0 to ±99999999

[Standard value] 0

[Description] Specify the points for the output range of the area signals using machine

coordinates. Area signals PSG1 and PSG2 are output according to the

result of comparison between the machine coordinate and a

parameter-specified value. The output conditions are listed below.

ABSMT represents the current machine coordinate.

Condition PSG2 PSG1

ABSMT < point 1 0 0

Point 1 ≤ ABSMT < point 2 0 1

Point 2 ≤ ABSMT < point 3 1 0

Point 3 ≤ ABSMT 1 1

NOTE

When bit 1 (PSSV) of parameter No. 007 is 1, area

signals can be input at actual motor position where

allowance for delays including an

acceleration/deceleration delay and motor delay is

made.

166 Operation completion signal output time

[Size] 4-byte

[Unit of data] 8msec

[Valid data range] 0 to 99999999

[Standard value] 5

[Description] Specifies the output time for operation completion signals OPC1 to

OPC4.

NOTE

If 0 is set, no operation completion signal is not

output.
