SERVO AMPLIFIER Beta i series Maintenance manual Page 296

Maintenance manual

Page of 366

/ 366

B.PARAMETER LIST APPENDIX B-65395EN/01

- 264 -

B.6 SERVO PARAMETERS

No #7 #6 #5 #4 #3 #2 #1 #0

010 SVFP ECMR ZMIX IEBL IALM IINP

[Size] 1 byte (bit type)

[Standard value] 1 for SVFP only

IINP Specifies whether to make in-position check when the torque is limited,

as follows:

0 : In-position check is not made.

1 : In-position check is made.

NOTE

This parameter is valid, when parameter No.0108 is

not 0 and IEBL = 1.

IALM Specifies whether to check for a stop- and movement-time excessive

error when the torque is limited, as follows:

0 : An error check is not made.

1 : An error check is made.

NOTE

This parameter is valid, when parameter No.0108 is

not 0 and IEBL = 1.

IEBL Specifies whether to enable the torque limit function, as follows:

0 : Disable

1 : Enable

ZMIX Specifies the initial direction of backlash and grid movement in a

reference position return without dogs, as follows:

0 : Positive direction

1 : Negative direction

ECMR Specifies whether to enable expansion of the setting range for the

command multiplier, as follows:

0 : Disabled. (The setting of parameter No. 032 is valid for the

command multiplier.)

1 : Enabled. (The setting of parameter No. 138 is valid for the

command multiplier.)

SVFP Specifies whether to perform follow-up, as follows:

0 : Follow-up is not performed.

1 : Follow-up is performed.
