3.FP FUNCTIONS B-66284EN/01

- 294 -

3.1.2 FANUC PICTURE CNC window library

[Functions]

* Those functions whose names are underlined accept a path

specification.

Function name Description

1.1 sysinfo

Reading CNC system information

1.2 rdproginfo

Reading program information

1.3 rdprgnum

Reading the current program number

1.4 rdseqnum

Reading the current sequence number

1.5 actf

Reading the actual feedrate (F) of the controlled

axis

1.6 acts

Reading the actual spindle speed (S)

1.7 absolute

Reading the absolute position of a controlled axis

1.8 machine

Reading the machine position of a controlled axis

1.9 relative

Reading the relative position of a controlled axis

1.10 distance

Reading the remaining amount of travel along a

controlled axis

1.11 skip

Reading the skip position of a controlled axis

1.12 srvdelay

Reading the servo delay of a controlled axis

1.13 accdecdly

Reading the acceleration/deceleration delay of a

controlled axis

1.14 statinfo

Reading CNC status information

1.15 alarm

Reading the alarm status

1.16 rdtofs

Reading the tool offset value

1.17 rdzofs

Reading the workpiece origin offset

1.18 rdparam

Reading a parameter

1.19 rdset

Reading a setting

1.20 rdpitchr

Reading pitch error compensation data (with the

input range specified)

1.21 diagnoss

Reading diagnosis data

1.22 adcnv

Reading A/D conversion data

1.23 rdgrpid

Reading tool life management data (tool group

number)

1.24 rdngrp

Reading tool life management data (the number

of tool groups)

1.25 rdntool

Reading tool life management data (the number

of tools)

1.26 rdlife

Reading tool life management data (tool life)

1.27 rdcount

Reading tool life management data (tool life

counter)

1.28 rd1length

Reading tool life management data (tool length

compensation number 1)

1.29 rd2length

Reading tool life management data (tool length

compensation number 2)

1.30 rd1radius

Reading tool life management data (cutter

compensation number 1)

1.31 rd2radius

Reading tool life management data (cutter

compensation number 2)

1.32 t1info

Reading tool life management data (tool

information 1)
