PROGRAMMING12. COMPENSATION FUNCTION
B–63664EN/02
222
When a beam with a rotation axis (C–axis) is moved in the XY plane
during cutting, the normal direction control function can control the beam
so that the C–axis is always perpendicular to the beam path (Fig.12.7 (a)).
C–axis
Programmed
beam path
Normal
direction
Programmed
beam path
C–axis
Fig.12.7 (a) Nozzle Operation (Example)
G code
Function Explanation
G41.1 or G151
Normal direction
control left
If the workpiece is to the right of the
nozzle path looking toward th
direction in which the nozzle ad
vances, the normal direction con
-
trol left (G41.1 or G151) function is
G42.1 or G152
Normal direction
control right
trol left (G41.1 or G151) function is
specified.
After G41.1 (or G151) or G42.1 (o
G152) is specified, the norma
direction control function is en
-
abled (normal direction control
G40.1 or G150
Normal direction
control cancel
abled (normal direction control
mode).
When G40.1 (or G150) is spec
fied, the normal direction contro
mode is canceled.
12.7
NORMAL DIRECTION
CONTROL (G40.1,
G41.1, G42.1 OR
G150, G151, G152)
Format
