OPERATION
B–63664EN/02
11. SETTING AND DISPLAYING DATA
695
PROGRAM (NUM.) MEMORY (CHAR.)
USED: 60 3321
FREE: 2 429
O0001 1,360 1996–06–12 14:40
O0002 1,240 1996–06–12 14:55
O0010 1,420 1996–07–01 11:02
O0020 1,180 1996–08–14 09:40
O0040 1,140 1996–03–25 18:40
O0050 1,160 1996–08–26 16:40
O0100 1,120 1996–04–03 13:11
> _
EDIT **** *** *** 16:05:59
[ PRGRM ] [ DIR+ ] [ ] [ C.A.P. ] [ (OPRT) ]
PROGRAM DIRECTORY O0001 N00010
Fig.11.3.1 (b)
When the NAM parameter (No.3107#0) is 0, only program numbers are
displayed.
Always enter a program name between the control out and control in
codes immediately after the program number.
Up to 31 characters can be used for naming a program within the
parentheses. If 31 characters are exceeded, the exceeded characters are
not displayed.
Only program number is displayed for the program without any program
name.
(∆∆∆∆…∆)
f
;
Program number
Program name (up to 31 characters)
jjjj
Programs are displayed in the same order that they are registered in the
program library list. However, if bit 4 (SOR) of parameter 3107 is set to
1, programs are displayed in the order of program number starting from
the smallest one.
When no program has been deleted from the list, each program is
registered at the end of the list.
If some programs in the list were deleted, then a new program is
registered, the new program is inserted in the empty location in the list
created by the deleted programs.
Example) When bit 4 (SOR) of parameter 3107 is 0
1. After clearing all programs, register programs O0001, O0002, O0003,
O0004, and O0005 in this order. The program library list displays the
programs in the following order:
O0001, O0002, O0003, O0004, O0005
2. Delete O0002 and O0004. The program library list displays the
programs in the following order:
O0001, O0003, O0005
3. Register O0009. The program library list displays the programs in the
following order:
O0001, O0009, O0003, O0005
D Program name
D Order in which programs
are displayed in the
program library list
D Order in which programs
are registered
