PROGRAMMING 18. SPECIFYING THE LASER FUNCTION
B–63664EN/02
363
The edge machining function is used to sharpen an edge of a workpiece.
This function consists of edge detection, gradual stop control, piercing,
and control over the power and feedrate used in the transition from
piercing to machining. This function is useful for an edge that is smaller
than a specified angle.
When an edge data number is set in the edge selection item of the
machining data group on the machining condition setting screen, the edge
machining function is enabled. This means that edge machining is applied
not to the nozzle path on the program but to the offset nozzle path.
To disable the edge machining function, set 0 in the edge selection item.
No. FEED PWR FREQ DUTY GAS GAS GAS DEF EDGE APPR POWER CTL
1 ***** **** **** *** **.* ** *.* –*.*** –*.*** 201 *** ***
2 ***** **** **** *** **.* ** *.* –*.*** –*.*** 0 *** ***
3 ***** **** **** *** **.* ** *.* –*.*** –*.*** 205 *** ***
4 ***** **** **** *** **.* ** *.* –*.*** –*.*** 203 *** ***
5 ***** **** **** *** **.* ** *.* –*.*** –*.*** 204 *** ***
If a machining data set number is specified in address E in the machining
program, the edge selection item in the specified machining data is
referenced when the program is executed. Then, the edge data set number
is read to perform edge machining.
S For an explanation of data setting, see Section III–15.9.
18.7.4
Edge Machining
Function
Enabling/disabling the
edge machining function
Screen
