PROGRAMMING18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

340

Whether the laser power control function is to be enabled or disabled can

be specified using the laser setup screen or a parameter.

1) Specification using the laser setup screen

The laser power control function is enabled by setting the power

control item on the laser setup screen to 1.

S Power control (on the laser setup screen)

1: The laser power control function can be used.

0: The laser power control function cannot be used. When this value

is set, laser power control mode, described later, cannot be set.

2) Specification using a parameter

The laser power control function is enabled by setting bit 0 (LPC) of

parameter No. 15000 to 1.

S Bit 0 (LPC) of parameter No. 15000

1: The laser power control function can be used.

0: The laser power control function cannot be used. When this value

is set, laser power control mode, described later, cannot be set.

Any of the control items, peak power, pulse frequency, and pulse duty, can

be selected using a parameter (PRM.15096). More than one item can be

selected.

If none of these items is selected, no power control is performed.

The power control function uses the nozzle feedrate to calculate each laser

output factor (peak power, pulse frequency, and pulse duty). To get hold

of this feedrate accurately, you must specify which machine axis is related

to the operation of the nozzle, using parameter No. 15089.

If this parameter is omitted, the first and second axes are assumed to have

been set up.

An axis subjected to simplified synchronization control is related to the

movement of the nozzle. This axis, together with the master axis, should

be excluded from the setting.

If the laser power control function is enabled using the laser setup screen

or the appropriate parameter, the peak power, pulse frequency, and pulse

duty can be controlled in proportion to the feedrate by specifying G63P1.

The system is returned from laser power control mode either by

specifying G63P0 or by entering a reset signal (laser power control mode

is canceled).

D Specifying whether to

enable or disable the

function

D Selecting the control

item

D Axes that can be

subjected to power

control

D Laser power control

mode
