OPERATION
B–63664EN/02
15. LASER FUNCTION
797
The current data of laser are displayed.
1 Press
OFFSET
SETTING
key, and the following soft keys are displayed.
POWER SET DATA
2 Press next- menu key .
3 Press [STATUS] key.
4 Laser status screen is displayed as follows.
MAT. ***********
E CODE CUTTING *** PIERCING ***
F FEED ***** mm/min
PC POWER **** W
FR FREQUENCY **** Hz
D
U
DUTY *** %
GK GAS SELECT *
GP GAS PRESSURE *.** MPA
ER DEFLECTION –*.*** mm
D OFFSET *.*** mm
STATUS
O ***** N *****
FA FEED ***** mm/min
PA POWER **** W
X –*****.***
Y –*****.***
Z –*****.***
4 –*****.***
E–code : The current data set number for cutting and
piercing of processing condition setting
function is shown.
Feedrate (F) : The commanded feedrate is shown.
Unit mm/ min
Command power (P
C
) : The commanded laser peak power before
applying override is shown.
Unit Watt (W)
Pulse frequency (F
R
) : The commanded pulse frequency is shown.
Unit Hertz (Hz)
Pulse duty (D
U
) : The commanded pulse duty is shown.
Unit %
Assist gas select (Gk) : The commanded assist gas select is shown.
Assist gas pressure (Gp) : The actual assist gas pressure is shown.
Unit MPa
Error of gap control (E) : Error of gap control is shown.
Unit mm
Offset value (D) : The current tool offset value is shown.
Unit mm
Program No. (O) : The current program No. is shown.
Sequence No. (N) : The current sequence No. in a part program is
shown.
Actual feedrate (F
A
) : Actual feedrate is shown.
Unit mm/ min
Actual power (P
A
) : Actual laser power is shown.
Unit Watt (W)
Position : The current position in the relative coordinate
is shown.
15.10
LASER STATUS
SCREEN
Procedure
Explanations
D Meaning of items
