PROGRAMMING
19. THREE–DIMENSIONAL
CUTTING FUNCTION
B–63664EN/02
406
15621 Maximum speed 1 after position control
[Data type] Two–word axis
[Unit of data, valid data range]
Increment system Unit of data IS–A, IS–B IS–C
Millimeter machine 1 mm/min or 1 deg/min 0 to 240000 0 to 100000
Inch machine 0.1 inch/min or 1 deg/min 0 to 96000 0 to 48000
Specify the maximum speed after position control. The speed on each
axis may be overridden so as not to exceed this setting.
The maximum speed check is not performed on an axis for which 0 is set.
15622 Maximum speed 2 after position control
[Data type] Two–word axis
[Unit of data, valid data range]
Increment system Unit of data IS–A, IS–B IS–C
Millimeter machine 1 mm/min or 1 deg/min 0 to 240000 0 to 100000
Inch machine 0.1 inch/min or 1 deg/min 0 to 96000 0 to 48000
Specify the maximum speed after position control. The speed on each
axis may be overridden so as not to exceed this setting. This parameter is
effective when the position control B speed clamp select signal (G224#7,
OTPMX2) is 1. When OTPMX2 is 0, parameter No. 15621 is effective.
Parameter No. 15621 is effective to an axis for which 0 is set in this
parameter.
#7
OTPMX2G224
#6 #5 #4 #3 #2 #1 #0
Position control B feedrate clamp switching signal
OTPMX2 Selects which parameter is to be used to specify the maximum value for
automatic feedrate overriding under position control B.
1 : Automatic overriding occurs based on parameter No. 15621.
0 : Automatic overriding occurs based on parameter No. 15622.
Parameters
Signal
