16i/160i-LB Operators manual Page 799

Operators manual
OPERATION
B–63664EN/02
15. LASER FUNCTION
775
Name Power (half)
Meaning Specified power compensation output value when half of
discharge tubes are used
Parameter No.15200
Valid data range 0 to 9999
Name Power (all)
Meaning Specified power compensation output value when all
discharge tubes are used
Parameter No.15201
Valid data range 0 to 9999
Name Frequency
Meaning Specified frequency during power compensation
Parameter No.15321
Valid data range 0 to 2000
Name Duty
Meaning Specified duty cycle during power compensation
Parameter No.15322
Valid data range 0 to 100
Name Compensation time
Meaning Power compensation time setting
Parameter No.15205
Valid data range 0 to 32767
Name Gas pressure (50 Hz)
Meaning Value of pressure in tubes during oscillation
Parameter No.15242
Valid data range 0 to 32767
Name Gas pressure (60 Hz)
Meaning Value of pressure in tubes during oscillation
Parameter No.15243
Valid data range 0 to 32767
