PROGRAMMING16. HIGH SPEED CUTTING FUNCTIONS

B–63664EN/02

298

S, P, Q, E : Specifying a laser output condition (the feedrate and tool

compensation amount cannot be changed)

Data for movement along axis : Data for moving the tool along the

axis set in parameter No. 1020 (any

axis selected from X, Y, Z, U, V, W, A,

B, and C)

( ) : Control–in and control–out commands

(comment specification)

/n : Optional block skip command (n is a number.)

Mxxxx : Auxiliary function (Note)

Txxxx : Auxiliary function (Note)

Bxxxx : Auxiliary function (Note)

M98, M198, etc. : Subprogram call

NOTE

1 G00, auxiliary functions, subprogram call (M98, M198), and macro

call M and T codes can be specified in the HPCC mode only when

bit 1 of parameter MSU No. 8403 is 1. If these codes are specified

when MSU is not 1, an alarm is issued.

(Alarm No.5012 for G00 and alarm No.9 for auxiliary functions and

subprogram calls)

2 To specify the following functions in HPCC mode, the following

parameters are required. Specifying any of the following functions

without setting the corresponding parameter causes an alarm.

Helical interpolation : Parameter G02 (No.8485*)

(Alarm to be issued: No.28)

Scaling, coordinate rotation : Parameter G51 (No. 8485)

(Alarm to be issued: No.10)
