OPERATION15. LASER FUNCTION

B–63664EN/02

798

When the target point and the basic point is specified, an arbitrary point

in the coordinate system of a part program is converted into the part

program by three dimensions. The mirror image conversion and three

dimension movement conversion are prepared as three-variable

transform function.

1 When the function key

OFFSET

SETTING

is pushed, the softkey is displayed as

follows.

POWER SET DATA 3D.TRN

2 Push the soft key [3D. TRN].

3 The mirror image source screen is displayed as follows.

MIRROR IMAGE SOURCE O0001 N0001

SOURCE (P) DESTINA. (Q)

X–99999.999 X–99999.999

#0 Y–99999.999 Y–99999.999

Z–99999.999 Z–99999.999

[ POWER ][ SET ][ DATA ][ 3D.TRN ][ ]

SHIFT FUNC. O0001 N0001

SOURCE (P) DESTINA. (Q)

X–99999.999 X–99999.999

#1 Y–99999.999 Y–99999.999

Z–99999.999 Z–99999.999

X–99999.999 X–99999.999

#2 Y–99999.999 Y–99999.999

Z–99999.999 Z–99999.999

#3 Y–99999.999 Y–99999.999

Z–99999.999 Z–99999.999

[ POWER ][ SET ][ DATA ][ 3D.TRN ][ ]

4 The screen consists of the mirror image source conversion and the

three dimension movement conversion. It is 2 page, and change the

page by the page key.

5 Move the cursor on the item where data must be set, and push the

function key

INPUT

after inputting value.

It is impossoble to set these data during operating a part program.

15.11

THREE–VARIABLE

TRANSFORM

FUNCTION

Procedure

Limitations
