OPERATION

4. AUTOMATIC OPERATION

B–63664EN/02

500

When the NC is stopped, the number of executed blocks is displayed on

the program screen or program restart screen. The operator can specify the

number of the block from which the program is to be restarted, by noting

the number displayed on the screen. The displayed number indicates the

number of the block that was executed most recently. For example, to

restart the program from the block at which execution stopped, specify the

value of the displayed number + 1.

The number of blocks is counted from the start of processing, assuming

one NC statement line of a CNC program to be one block.

< Example 1 >

CNC Program Number of blocks

O 0001 ;

G90 G92 X0 Y0 Z0 ;

G01 X100. F100 ;

G03 X01 –50. F50 ;

M30 ;

< Example 2 >

CNC Program Number of blocks

O 0001 ;

G90 G92 X0 Y0 Z0 ;

G90 G00 Z100. ;

G81 X100. Y0. Z–120. R–80. F50. ;

#1 = #1 + 1 ;

#2 = #2 + 1 ;

#3 = #3 + 1 ;

G00 X0 Z0 ;

M30 ;

Macro statements are not counted as blocks.

The number of blocks is also stored after the power is turned off. The

stored number of blocks is cleared by cycle start in reset state.

The program screen usually displays the number of the block being

executed. Once the execution of a block is complete, the CNC is reset, or

the program is stopped by single–block stop, the program screen displays

the number of the block that was executed most recently

When a CNC program is halted or stopped by feed hold, reset, or

single–block stop, the following block numbers are displayed:

Feed hold : Block being executed

Reset : Block executed most recently

Single–block stop : Block executed most recently

For example, when the CNC is reset during the execution of block 10, the

displayed block number changes from 10 to 9.

When MDI intervention is performed while the program is stopped by

single–block stop, the CNC commands used for intervention are not

counted as blocks.

When the length of the block number displayed on the program screen

exceeds eight digits, the block number is reset to 0 and counting

continues.

Explanations

D Block number

D Storing and clearing the

number of blocks

D Block number displayed

when a program is

halted or stopped

D MDI intervention

D Block number consisting

of more than eight digits
