PROGRAMMING 18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

337

Specifies the initial pulse duty (ratio of the pulse ON time to the pulse

period) during piercing.

Specifies the pulse frequency increment per step during piercing.

Specifies the increment of the pulse duty (ratio of the pulse ON time to

the pulse period) per step during piercing.

Specifies the duration of a single step during piercing.

Specifies the total number of steps during piercing.

Specifies the duration that piercing is to be performed. The duration must

be greater than the step time multiplied by the number of steps. If it is

shorter, piercing will terminate once the piercing time has elapsed, before

the specified number of steps are executed.

Table 18.2 Valid Ranges

Item

Valid range Unit Parameter

S_ 0 to 7000W 1W 15080

P_ 5 to 2000Hz 1Hz 15081

Q_ 0 to 100% 1% 15082

I_ 0 to 2000Hz 1Hz 15083

J_ 0 to 100% 1% 15084

K_ 0 to 32767msec 1msec 15085

H_ 0 to 32767 1 15086

R_ 0 to 99999999msec 1msec 15087

If only the data for piercing is to be changed without performing piercing,

G10 can be used to specify the parameters corresponding to the desired

data items.

G10 L50; Data setting mode

N_R_; N=Parameter number, R=Data item

N_R_: N=Parameter number, R=Data item

. . . . .

G11; Data setting mode cancel

During piercing, the piercing time can be extended or shortened by using

an external signal.

S When ”Extend” is performed during piercing, the final continuation

time is extended.

S When ”Shorten” is performed during piercing, piercing terminates at

the rising edge of a signal.

S Whether the piercing time set for a parameter is to be updated with the

actual piercing time when Extend or Shorten is performed can be

specified using a parameter.

D Initial pulse duty

D Pulse frequency

increment

D Pulse duty increment

D Step time

D Number of steps

D Piercing time

D Data change command

D Function for changing

the piercing time

externally
