16i/160i-LB Operators manual Page 267

Operators manual

Page of 912

/ 912

PROGRAMMING

B–63664EN/02

13. CUSTOM MACRO

243

By reading the following custom macro variables, the most recently

specified E code including program preprocessing can be read.

Table 13.2 (m) System variables for the cutting condition setting function

Variable

number

Function

#6032 Look–ahead piercing E code

#6033 Look–ahead cutting E code

S #6032 and #6033 are variables for read only. If an attempt is made to

write data to these variables, alarm 116 is issued.

S When reading these variables with the macro executor, add 100000 to

variable numbers #6032 and #6033, and specify #106032 and

#106033, respectively.

S If the cutting condition setting function option is not provided, these

variables read 0.

S Use these variables in machining programs (such as custom macro

calls and execution macro calls).

S E codes written with #6030 and #6031 cannot be read.

The Z–axis motion in the gap controlled axis automatic save/restore

function can be modified by rewriting the contents of the following

custom macro variables:

Table 13.2 (n) System variables for the gap controlled axis automatic

save/restore function

Variable

number

Function

#6048 X– and Y–axis motion start position (PRM. No.15865)

#6049 Deceleration start position (PRM. No.15866)

#6050 Function end position (PRM. No.15867)

For details of the function, refer to “FS16i–LB Connection Manual”

(B–63663EN).

The operation of the function for beam output during approach can be

modified by rewriting the contents of the following custom macro variables:

Table 13.2 (o) System variables for the function for beam output during

approach

Variable

number

Function

#6051 Gap deviation value at which beam output starts (parameter No. 15870)

#6052 Adjustment ratio of gap control axis speed (parameter No. 15871)

#6053 Gap control axis control extension time (parameter No. 15872)

For details of the function, refer to “FS16i–LB Connection Manual”

(B–63663EN).

NOTE

1 While the function for beam output during Z–axis approach

is operating, do not change the content of #6051.

2 Do not assign any negative value to #6052 and #6053.

D Cutting condition setting

function

D Gap controlled axis

automatic save/restore

function

D Function for beam output

during approach
