OPERATION
B–63664EN/02
15. LASER FUNCTION
765
The following data items are displayed on the laser power screen.
@ Current output power
@ Actual output power
@ Pulse frequency
@ Pulse duty
@ Error
1 Press the
OFFSET
SETTING
function key.
2 Press the [POWER] soft key.
LASER POWER O0000 N00000
PC 1000 W
PA 1000 W
FR 2000 Hz
DU 100 %
E 0.000 MM
S 0 T0000
MDI **** *** *** 21:20:07
[ POWER ][ SET ][ ][ ][ ]
Fig.15.1
Current output power (P
C
) : Displays the currently specified output
power in Watt (W) .
The data indicates the value before a power
override is applied.
Actual output power (P
A
) : Displays the actual output power in Watt
(W) .
Pulse frequency (F
R
) : Displays the currently specified pulse
frequency in Hertz (Hz) .
Pulse duty (D
U
) : Displays the currently specified pulse duty
as a percentage (%) .
Error (E) : Displays the error of Z-axis gap control in
mm.
Data items, P
C
, F
R
, and D
U
normally show contouring data. During
piercing, they show piercing data.
15.1
LASER POWER
SCREEN
Procedure
Explanations
D Data items
D Piercing data
