APPENDIX
B–63664EN/02
G. ALARM LIST
855
The details of serial pulse coder alarm No. 351 (communication alarm)
are displayed in the diagnosis display (No. 203) as shown below.
#7 #6 #5 #4 #3 #2 #1 #0
DTE
CRC
STB PRM203
PRM: An invalid parameter was found. Alarm No. 417 (invalid servo
parameter) is also issued.
STB : the serial pulse coder encountered a communication error.
The pulse coder, feedback cable, or feedback receiver circuit
is defective.
Replace the pulse coder, feedback cable, or NC–axis board.
CRC: The serial pulse coder encountered a communication error.
The pulse coder, feedback cable, or feedback receiver circuit
is defective. Replace the pulse coder, feedback cable, or
NC–axis board.
DTE : The serial pulse coder encountered a communication error.
The pulse coder, feedbak cable, or feedback receiver circuit
is defective. Replace the pulse coder, feedback cable, or
NC–axis board
6) Servo alarms
Number Message Contents
401 SERVO ALARM: n–TH AXIS VRDY
OFF
The n–th axis (axis 1 to 8) servo amplifier READY signal (DRDY) went off.
Refer to procedure of trouble shooting.
402 SERVO ALARM: SV CARD NOT EX-
IST
The axis control card is not provided.
403 SERVO ALARM: CARD/SOFT MIS-
MATCH
The combination of the axis control card and servo software is illegal.
The possible causes are as follows:
· A correct axis control card is not provided.
· Correct servo software is not installed on flash memory.
404 SERVO ALARM: n–TH AXIS VRDY
ON
Even though the n–th axis (axis 1 to 8) READY signal (MCON) went off,
the servo amplifier READY signal (DRDY) is still on. Or, when the power
was turned on, DRDY went on even though MCON was off.
Check that the servo interface module and servo amp are connected.
405 SERVO ALARM: (ZERO POINT RE-
TURN FAULT)
Position control system fault. Due to an NC or servo system fault in the
reference position return, there is the possibility that reference position
return could not be executed correctly. Try again from the manual refer-
ence position return.
407 SERVO ALARM: EXCESS ERROR The following failure occurred during simplified synchronization control.
1) The difference in synchronous axis position deviation exceeded the
value set in parameter No. 8314.
409 SERVO ALARM: n AXIS TORQUE
ALM
Abnormal servo motor load has been detected.
410 SERVO ALARM: n–TH AXIS – EX-
CESS ERROR
Either of the following failures occurred.
1) The position deviation when the n axis stops exceeded the value set
in parameter No. 1829.
2) The amount of compensation for synchronization exceeded the value
set in parameter No. 8325 during simplified synchronization control.
This alarm can be generated only for the slave axis.
411 SERVO ALARM: n–TH AXIS – EX-
CESS ERROR
The position deviation value when the n–th axis (axis 1 to 8) moves is
larger than the set value.
413 SERVO ALARM: n–th AXIS – LSI
OVERFLOW
The contents of the error register for the n–th axis (axis 1 to 8) exceeded
"2
31
power. This error usually occurs as the result of an improperly set
parameters.
415 SERVO ALARM: n–TH AXIS – EX-
CESS SHIFT
A speed higher than 524288000 units/s was attempted to be set in the
n–th axis (axis 1 to 8). This error occurs as the result of improperly set
CMR.
D The details of serial
pulse coder alarm
No.351
