OPERATION8. DATA INPUT/OUTPUT B–63664EN/02

618

9 Press the [EXEC] soft key.

10 During output, “OUTPUT” blinks in the lower–right corner of the

screen.

NOTE

An outputted file name is Oxxxx.

With the FTP file transfer function, the types of data listed below can be

input/output. This subsection describes the input/output method.

A) NC parameter

B) Tool offset value

C) Custom macro variable

D) Workpiece orogin offset value

E) Pitch error compensation data

F) M code group

G) Operation history data

Parameter input

The file (NC parameter) on the host computer can be input to the CNC

memory.

1 Place the CNC in the EDIT mode.

2 Press the function key

SYSTEM

3 Press the continuous menu key at the right end of the soft key display.

4 Press the [PARAM] soft key. The parameter screen appears.

5 Press the [(OPRT)] soft key.

6 Press the continuous menu key at the right end of the soft key display.

7 Press the [READ] soft key.

8 Press the [EXEC] soft key.

9 During input, “INPUT” blinks in the lower–right corner of the screen.

The fixed file name PRAMETER is used.

Refer to the operator’s manual of each CNC.

8.12.1.6

Input/output of various

types of data

Procedure

File name

File format, restrictions
