PROGRAMMING16. HIGH SPEED CUTTING FUNCTIONS

B–63664EN/02

300

S When the offset mode is canceled temporarily

In the HPCC mode, automatic reference position return (G28) and

automatic return from the reference position (G29) cannot be

specified. Therefore, commands that must cancel the offset mode

temporarily cannot be specified.

When using cutter compensation C in the HPCC mode, note the following

points:

(1)When G05 P10000 and G05 P0, and G41/G42 and G40 are to be

specified together, G41/G42 to G40 must be nested between G05

P10000 and G05 P0. This means that HPCC mode cannot be started

or canceled in cutter compensation (G41/G42) mode. If such a

specification is made, the P/S alarm No.0178 or P/S alarm No.5013

P/S alarm is issued.

G05 P10000 ;

G41 X__ Y__ D01 ;

G40 X__ Y__ ;

G42 X__ Y__ D02 ;

G40 X__ Y__ ;

G05 P0 ;

(Example of a correct program)

Cutter compensation

(G41) mode

Cutter compensation

(G42) mode

HPCC mode

G41 X__ Y__ D01 ;

G05 P10000 ;

G41 X__ Y__ D01 ;

G05 P0 ;

(Example of an incorrect program (1))

When the start of HPCC mode is specified

in cutter compensation mode, the P/S

alarm No.0178 is issued.

(Example of an incorrect program (2))

When cancellation of HPCC mode is specified

in cutter compensation mode, the P/S alarm

No.5013 alarm is issued.
