OPERATION

B–63664EN/02

12. GRAPHICS FUNCTION

729

GRAPHICS FUNCTION

Two graphic functions are available. One is a graphic display function,

and the other is a dynamic graphic display function.

The graphic display function can draw the beam path specified by a

program being executed on a screen. The graphic display function also

allows enlargement and reduction of the display.

The dynamic graphic display function can draw a beam path and

machining profile.

In beam path drawing, automatic scaling and solid drawing are possible.

In machining profile drawing, the status of machining in progress can be

drawn through simulation. Blank figures can also be drawn.

This chapter mainly explains drawing procedures and drawing

parameters for the following:

1. Drawing the beam path specified by a program being executed, with

the graphic display function

2. Drawing the beam path with the dynamic graphic display function

3. Drawing the machining profile with the dynamic graphic display

function
